In today’s fast-paced world of software development, automation is the name of the game. GitHub Actions is the ace up the sleeve of modern developers, enabling them to streamline their daily workflows in practical and impactful ways. In this article, we’ll explore how GitHub Actions is making a real difference in real-life scenarios.

From Continuous Integration (CI) and Continuous Deployment (CD) to code quality assurance and security scanning, GitHub Actions brings automation to every aspect of the development process. With custom workflows, enhanced collaboration, and release management, this tool empowers developers to be more efficient, reliable, and productive. Discover how GitHub Actions is not just a concept but a transformative solution in the daily lives of developers.

GitHub: https://github.com/Aj7Ay/Myntra-Clone.git

STEP 1A: Setting up AWS EC2 Instance and IAM Role

1. Sign in to the AWS Management Console: Access the AWS Management Console using your credentials
2. Navigate to the EC2 Dashboard: Click on the “Services” menu at the top of the page and select “EC2” under the “Compute” section. This will take you to the EC2 Dashboard.
3. Launch Instance: Click on the “Instances” link on the left sidebar and then click the “Launch Instance” button.
4. Choose an Amazon Machine Image (AMI): In the “Step 1: Choose an Amazon Machine Image (AMI)” section:
   • Select “AWS Marketplace” from the left-hand sidebar.
   • Search for “Ubuntu” in the search bar and choose the desired Ubuntu AMI (e.g., Ubuntu Server 22.04 LTS).
   • Click on “Select” to proceed.
5. Choose an Instance Type: In the “Step 2: Choose an Instance Type” section:
   • Scroll through the instance types and select “t2.large” from the list.
   • Click on “Next: Configure Instance Details” at the bottom.
6. Configure Instance Details: In the “Step 3: Configure Instance Details” section, you can leave most settings as default for now. However, you can configure settings like the network, subnet, IAM role, etc., according to your requirements.
   • Once done, click on “Next: Add Storage.”
7. Add Storage: In the “Step 4: Add Storage” section:
   • You can set the size of the root volume (usually /dev/sda1) to 30 GB by specifying the desired size in the “Size (GiB)” field.
   • Customize other storage settings if needed.
   • Click on “Next: Add Tags” when finished.
8. Add Tags (Optional): In the “Step 5: Add Tags” section, you can add tags to your instance for better identification and management. This step is optional but recommended for organizational purposes.
   • Click on “Next: Configure Security Group” when done.
9. Configure Security Group: In the “Step 6: Configure Security Group” section:
   • Create a new security group or select an existing one.
   • Ensure that at least SSH (port 22) is open for inbound traffic to allow remote access.
   • You might also want to open other ports as needed for your application’s requirements.
   • Click on “Review and Launch” when finished.
10. Review and Launch: Review the configuration details of your instance. If everything looks good:
    • Click on “Launch” to proceed.
    • A pop-up will prompt you to select or create a key pair. Choose an existing key pair or create a new one.
    • Finally, click on “Launch Instances.”
11. Accessing the Instance: Once the instance is launched, you can connect to it using SSH. Use the private key associated with the selected key pair to connect to the instance’s public IP or DNS address.

STEP 1B: IAM ROLE

Search for IAM in the search bar of AWS and click on roles.

Click on Create Role

Select entity type as AWS service

Use case as EC2 and click on Next.

For permission policy select Administrator Access (Just for learning purpose), click Next.

Provide a Name for Role and click on Create role.

Role is created.

Now Attach this role to Ec2 instance that we created earlier, so we can provision cluster from that instance.

Go to EC2 Dashboard and select the instance.

Click on Actions –> Security –> Modify IAM role.

Select the Role that created earlier and click on Update IAM role.

Connect the instance to Mobaxtreme or Putty.

STEP 2: INSTALL REQUIRED PACKAGES ON INSTANCE

Create Docker & Docker scout Installation script

vi docker-setup.sh

Script

# Add Docker's official GPG key:
sudo apt-get update
sudo apt-get install ca-certificates curl gnupg
sudo install -m 0755 -d /etc/apt/keyrings
curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo gpg --dearmor -o /etc/apt/keyrings/docker.gpg
sudo chmod a+r /etc/apt/keyrings/docker.gpg

# Add the repository to Apt sources:
echo \
  "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/ubuntu \
  $(. /etc/os-release && echo "$VERSION_CODENAME") stable" | \
  sudo tee /etc/apt/sources.list.d/docker.list > /dev/null
sudo apt-get update
sudo apt-get install docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin
curl -sSfL https://raw.githubusercontent.com/docker/scout-cli/main/install.sh | sh -s -- -b /usr/local/bin
sudo usermod -aG docker ubuntu
newgrp docker
sudo chmod 777 /var/run/docker.sock

Provide executable versions

sudo chmod 777 docker-setup.sh
sh docker-setup.sh

Create Script for other packages

vi script-packages.sh

Script

#!/bin/bash
sudo apt update -y
sudo touch /etc/apt/keyrings/adoptium.asc
sudo wget -O /etc/apt/keyrings/adoptium.asc https://packages.adoptium.net/artifactory/api/gpg/key/public
echo "deb [signed-by=/etc/apt/keyrings/adoptium.asc] https://packages.adoptium.net/artifactory/deb $(awk -F= '/^VERSION_CODENAME/{print$2}' /etc/os-release) main" | sudo tee /etc/apt/sources.list.d/adoptium.list
sudo apt update -y
sudo apt install temurin-17-jdk -y
/usr/bin/java --version

# Install Terraform
sudo apt install wget -y
wget -O- https://apt.releases.hashicorp.com/gpg | sudo gpg --dearmor -o /usr/share/keyrings/hashicorp-archive-keyring.gpg
echo "deb [signed-by=/usr/share/keyrings/hashicorp-archive-keyring.gpg] https://apt.releases.hashicorp.com $(lsb_release -cs) main" | sudo tee /etc/apt/sources.list.d/hashicorp.list
sudo apt update && sudo apt install terraform

# Install kubectl
sudo apt update
sudo apt install curl -y
curl -LO https://dl.k8s.io/release/$(curl -L -s https://dl.k8s.io/release/stable.txt)/bin/linux/amd64/kubectl
sudo install -o root -g root -m 0755 kubectl /usr/local/bin/kubectl
kubectl version --client

# Install AWS CLI
curl "https://awscli.amazonaws.com/awscli-exe-linux-x86_64.zip" -o "awscliv2.zip"
sudo apt-get install unzip -y
unzip awscliv2.zip
sudo ./aws/install

# Install Node.js 16 and npm
curl -fsSL https://deb.nodesource.com/gpgkey/nodesource.gpg.key | sudo gpg --dearmor -o /usr/share/keyrings/nodesource-archive-keyring.gpg
echo "deb [signed-by=/usr/share/keyrings/nodesource-archive-keyring.gpg] https://deb.nodesource.com/node_16.x focal main" | sudo tee /etc/apt/sources.list.d/nodesource.list
sudo apt update
sudo apt install -y nodejs

Give executable permissions for script and run it

sudo chmod 777 script-packages.sh
sh script-packages.sh

Check package versions

docker --version
terraform --version
aws --version
kubectl version
node -v
java --version

Run the Sonarqube container

docker run -d --name sonar -p 9000:9000 sonarqube:lts-community

Now copy the IP address of the ec2 instance

ec2-public-ip:9000

Provide Login and password

login admin
password admin

Update your Sonarqube password & This is the Sonarqube dashboard

Step 3: Integrating SonarQube with GitHub Actions

Integrating SonarQube with GitHub Actions allows you to automatically analyze your code for quality and security as part of your continuous integration pipeline.

We already have Sonarqube up and running

On Sonarqube Dashboard click on Manually

Next, provide a name for your project and provide a Branch name and click on setup

On the next page click on With GitHub actions

This will Generate an overview of the Project and provide some instructions to integrate

Let’s Open your GitHub and select your Repository

In my case it is Myntra-clone and Click on Settings

Search for Secrets and variables and click on and again click on actions

It will open a page like this click on New Repository secret

Now go back to Your Sonarqube Dashboard

Copy SONAR_TOKEN and click on Generate Token

Click on Generate

Let’s copy the Token and add it to GitHub secrets

Now go back to GitHub and Paste the copied name for the secret and token

Name: SONAR_TOKEN

Secret: Paste Your Token and click on Add secret

Now go back to the Sonarqube Dashboard

Copy the Name and Value

Go to GitHub now and paste-like this and click on add secret

Our Sonarqube secrets are added and you can see

Go to Sonarqube Dashboard and click on continue

Now create your Workflow for your Project. In my case, the Netflix project is built using React Js. That’s why I am selecting Other

Now it Generates and workflow for my Project

(Use your files for this block please)

Go back to GitHub. click on Add file and then create a new file

Go back to the Sonarqube dashboard and copy the file name and content

Here file name (in my case only )

sonar-project.properties

The content to add to the file is (copied from the above image)

sonar.projectKey=myntra

Add in GitHub like this (sample images)

Commit changes

Let’s add our workflow

To do that click on Add file and then click on Create a new file

Here is the file name

.github/workflows/build.yml  #you can use any name iam using sonar.yml

Copy content and add it to the file

name: Build,Analyze,scan

on:
  push:
    branches:
      - main


jobs:
  build-analyze-scan:
    name: Build
    runs-on: [self-hosted]
    steps:
      - name: Checkout code
        uses: actions/checkout@v2
        with:
          fetch-depth: 0  # Shallow clones should be disabled for a better relevancy of analysis

      - name: Build and analyze with SonarQube
        uses: sonarsource/sonarqube-scan-action@master
        env:
          SONAR_TOKEN: ${{ secrets.SONAR_TOKEN }}
          SONAR_HOST_URL: ${{ secrets.SONAR_HOST_URL }}

Commit changes

Now click on Actions

Click on Workflow

Click on build

Let’s click on Build and see what are the steps involved

Click on Run Sonarsource and you can do this after the build completion

Build complete.

Go to the Sonarqube dashboard and click on projects and you can see the analysis

If you want to see the full report, click on issues.

Step 4: Add GitHub Runner

Go to GitHub and click on Settings –> Actions –> Runners

Click on New self-hosted runner

Now select Linux and Architecture X64

Use the below commands to add a self-hosted runner

Go to Putty or Mobaxtreme and connect to your ec2 instance

And paste the commands

NOTE: USE YOUR RUNNER COMMANDS (EXAMPLE CASE IAM USING MINE)

mkdir actions-runner && cd actions-runner

The command “mkdir actions-runner && cd actions-runner” is used to create a new directory called “actions-runner” in the current working directory and then immediately change the current working directory to the newly created “actions-runner” directory. This allows you to organize your files and perform subsequent actions within the newly created directory without having to navigate to it separately.

curl -o actions-runner-linux-x64-2.310.2.tar.gz -L https://github.com/actions/runner/releases/download/v2.310.2/actions-runner-linux-x64-2.310.2.tar.gz

This command downloads a file called “actions-runner-linux-x64-2.310.2.tar.gz” from a specific web address on GitHub and saves it in your current directory.

Let’s validate the hash installation

echo "fb28a1c3715e0a6c5051af0e6eeff9c255009e2eec6fb08bc2708277fbb49f93  actions-runner-linux-x64-2.310.2.tar.gz" | shasum -a 256 -c

Now Extract the installer

tar xzf ./actions-runner-linux-x64-2.310.2.tar.gz

Let’s configure the runner

./config.sh --url https://github.com/Aj7Ay/Netflix-clone --token A2MXW4323ALGB72GGLH34NLFGI2T4

If you provide multiple labels use commas for each label

Let’s start runner

./run.sh

EKS provision

Clone the repo onto your instance

git clone https://github.com/Aj7Ay/Myntra-Clone.git
cd Myntra-Clone
cd EKS-TF

This changes the directory to EKS terraform files

Change your S3 bucket in the backend file

Initialize the terraform

terraform init

Validate the configuration and syntax of files

terraform validate

Plan and apply

terraform plan
terraform apply --auto-approve

It will take 10 minutes to create the cluster

Node group ec2 instance

Now add the remaining steps

Next, install npm dependencies

   - name: NPM Install
     run: npm install # Add your specific npm install command

This step runs npm install to install Node.js dependencies. You can replace this with your specific npm install command.

Create a Personal Access token for your Dockerhub account

Go to docker hub and click on your profile –> Account settings –> security –> New access token

It asks for a name Provide a name and click on generate token

Copy the token save it in a safe place, and close

Now Go to GitHub again and click on settings

Search for Secrets and variables and click on and again click on actions

It will open a page like this click on New Repository secret

Add your Dockerhub username with the secret name as

DOCKERHUB_USERNAME   #use your dockerhub username

Click on Add Secret.

Let’s add our token also and click on the new repository secret again

Name

DOCKERHUB_TOKEN

Paste the token that you generated and click on Add secret.

- name: Docker Login
  run: docker login -u ${{ secrets.DOCKERHUB_USERNAME }} -p ${{ secrets.DOCKERHUB_TOKEN }}

- name: Docker Scout Scan
  run: |
    docker-scout quickview fs://.
    docker-scout cves fs://.

- name: Docker build and push
  run: |
    # Run commands to build and push Docker images
    docker build -t myntra .
    docker tag myntra sevenajay/myntra:latest
    docker login -u ${{ secrets.DOCKERHUB_USERNAME }} -p ${{ secrets.DOCKERHUB_TOKEN }}
    docker push sevenajay/myntra:latest
   env:
     DOCKER_CLI_ACI: 1

- name: Docker Scout Image Scan
  run: |
    docker-scout quickview sevenajay/myntra:latest
    docker-scout cves sevenajay/myntra:latest

1. Docker Login:
   • This step is logging into Docker Hub using the provided Docker Hub username and token.
   • The Docker Hub username and token are stored as secrets (DOCKERHUB_USERNAME and DOCKERHUB_TOKEN), which is a best practice for keeping sensitive information secure.
2. Docker Scout Scan:
   • This step is using a tool called docker-scout to perform scans on the Docker image.
   • The quickview command is used to perform a quick review of the Docker image file system.
   • The cves command is used to check for Common Vulnerabilities and Exposures (CVEs) in the Docker image.
3. Docker build and push:
   • This step involves building a Docker image using the docker build command.
   • It then tags the built image with the name “sevenajay/myntra:latest” using the docker tag command.
   • Subsequently, it logs into Docker Hub again and pushes the built image to Docker Hub using the docker push command.
   • The env section sets an environment variable DOCKER_CLI_ACI to 1.
4. Docker Scout Image Scan:
   • Similar to the second step, this step performs scans on the Docker image that was just built and pushed to Docker Hub.
   • It uses docker-scout with the quickview and cves commands to inspect the image’s file system and check for vulnerabilities.

In summary, this workflow automates the process of building, tagging, and pushing a Docker image to Docker Hub. Additionally, it performs security scans on both the local Docker image and the pushed image on Docker Hub using the docker-scout tool.

Commit changes after adding the code.

Docker Image scan

Image is pushed to Dockerhub

DEPLOY

deploy:
  needs: build-analyze-scan
  runs-on: self-hosted # Use your self-hosted runner label here

This section defines another job named “deploy.” It specifies that this job depends on the successful completion of the “build-analyze-scan” job. It also runs on a self-hosted runner. You should replace self-hosted with the label of your self-hosted runner.

- name: Run the container
  run: docker run -d --name myntra -p 3000:3000 sevenajay/myntra:latest

This step runs a Docker container named “ticgame” in detached mode (-d). It maps port 3000 on the host to port 3000 in the container. It uses the Docker image tagged as sevenajay/myntra:latest.

If you run this workflow.

Output

Image scan report

Deployed to the container.

output

ec2-ip:3000

Deploy to EKS

- name: Update kubeconfig
  run: aws eks --region cluster-region update-kubeconfig --name cluster-name

This step updates the kubeconfig to configure kubectl to work with an Amazon EKS cluster in the region with the name of your cluster.

- name: Deploy to EKS
  run: kubectl apply -f deployment-service.yml

This step deploys Kubernetes resources defined in the deployment-service.yml file to the Amazon EKS cluster using kubectl apply.

Complete Workflow

name: Build,Analyze,scan

on:
  push:
    branches:
      - main


jobs:
  build-analyze-scan:
    name: Build
    runs-on: [self-hosted]
    steps:
      - name: Checkout code
        uses: actions/checkout@v2
        with:
          fetch-depth: 0  # Shallow clones should be disabled for a better relevancy of analysis

      - name: Build and analyze with SonarQube
        uses: sonarsource/sonarqube-scan-action@master
        env:
          SONAR_TOKEN: ${{ secrets.SONAR_TOKEN }}
          SONAR_HOST_URL: ${{ secrets.SONAR_HOST_URL }}

      - name: npm install dependency
        run: npm install

      - name: Docker Login
        run: docker login -u ${{ secrets.DOCKERHUB_USERNAME }} -p ${{ secrets.DOCKERHUB_TOKEN }}

      - name: Docker Scout Scan
        run: |
          docker-scout quickview fs://.
          docker-scout cves fs://.

      - name: Docker build and push
        run: |
          # Run commands to build and push Docker images
          docker build -t myntra .
          docker tag myntra sevenajay/myntra:latest
          docker login -u ${{ secrets.DOCKERHUB_USERNAME }} -p ${{ secrets.DOCKERHUB_TOKEN }}
          docker push sevenajay/myntra:latest
        env:
          DOCKER_CLI_ACI: 1

      - name: Docker Scout Image Scan
        run: |
          docker-scout quickview sevenajay/myntra:latest
          docker-scout cves sevenajay/myntra:latest

  deploy:
   needs: build-analyze-scan
   runs-on: [self-hosted]
   steps:
      - name: docker pull image
        run: docker pull sevenajay/myntra:latest

      - name: Deploy to container
        run: docker run -d --name game -p 3000:3000 sevenajay/myntra:latest

      - name: Update kubeconfig
        run: aws eks --region ap-south-1 update-kubeconfig --name EKS_CLOUD

      - name: Deploy to kubernetes
        run: kubectl apply -f deployment-service.yml

commit changes

Run this workflow now

Deployed to the container.

Deployed to EKS

Job completed.

Let’s go to the Ec2 ssh connection

Provide this command

kubectl get all

Open the port in the security group for the Node group instance.

After that copy the external IP and paste it into the browser

output

Destruction workflow

name: Build,Analyze,scan

on:
  push:
    branches:
      - main


jobs:
  build-analyze-scan:
    name: Build
    runs-on: [self-hosted]
    steps:
      - name: Checkout code
        uses: actions/checkout@v2
        with:
          fetch-depth: 0  # Shallow clones should be disabled for a better relevancy of analysis

      - name: Deploy to container
        run: |
          docker stop myntra
          docker rm myntra

      - name: Update kubeconfig
        run: aws eks --region ap-south-1 update-kubeconfig --name EKS_CLOUD

      - name: Deploy to kubernetes
        run: kubectl delete -f deployment-service.yml

It will delete the container and delete the Kubernetes deployment.

Stop the self-hosted runner.

Now go inside the Myntra-clone

To delete the Eks cluster

cd /home/ubuntu
cd Myntra-clone
cd EKS-TF
terraform destroy --auto-approve

It will take 10 minutes to destroy the EKS cluster

Meanwhile, delete the Dockerhub Token

Once cluster destroys

Delete The ec2 instance and IAM role.

Delete the secrets from GitHub also.
